Remote Control
R&S
®
ESR
741User Manual 1175.7068.02 ─ 12
Return values:
Result The result is returned in the form <result>, <result> where
<result> = PASSED | FAILED, and where the first returned value
denotes the lower, the second denotes the upper adjacent chan-
nel.
Example:
CALC:LIM:ACP:ACH 30DB, 30DB
Sets the relative limit value for the power in the lower and upper
adjacent channel to 30 dB below the channel power.
CALC:LIM:ACP:ACH:ABS -35DBM, -35DBM
Sets the absolute limit value for the power in the lower and
upper adjacent channel to -35 dB.
CALC:LIM:ACP ON
Switches on globally the limit check for the channel/adjacent
channel measurement.
CALC:LIM:ACP:ACH:STAT ON
Switches on the limit check for the adjacent channels.
INIT;*WAI
Starts a new measurement and waits for the sweep end.
CALC:LIM:ACP:ACH:RES?
Queries the limit check result in the adjacent channels.
Manual operation:
See "Limit Checking" on page 241
CALCulate<n>:LIMit<k>:ACPower:ALTernate<Channel>:ABSolute <LowerLimit>,
<UpperLimit>
This command defines the absolute limit value for the lower/upper alternate adjacent-
channel power measurement (Adjacent Channel Power).
Note that the absolute limit value for the limit check has no effect as soon as it is below
the relative limit value defined with CALCulate<n>:LIMit<k>:ACPower:
ACHannel[:RELative]. This mechanism allows automatic checking of the absolute
basic values defined in mobile radio standards for the power in adjacent channels.
Suffix:
<n>
.
Selects the measurement window.
<k> irrelevant
<Channel> 1...11
the alternate channel
Parameters:
<LowerLimit>,
<UpperLimit>
first value: -200DBM to 200DBM; limit for the lower and the
upper alternate adjacent channel
*RST: -200DBM
Example:
CALC:LIM:ACP:ALT2:ABS -35DBM, -35DBM
Sets the absolute limit value for the power in the lower and
upper second alternate adjacent channel to -35 dBm.
Remote Commands in Spectrum Analyzer Mode
