Channel Menu
Operating Manual 1145.1084.12 – 30 430
Two-port calibrations can be performed automatically or manually.
 Calibration Unit starts an automatic two-port TOSM calibration. This function is enabled while a
Calibration Unit is connected.
The following menu commands calls up the start dialog of the calibration wizard to start a manual
calibration:
 Normalization Both Directions... initiates a normalization using a through standard.
 One Path Two Port initiates a full one-port calibration.
 TOSM initiates a Through-Open-Short-Match (12-term) calibration
 UOSM iniates a TOSM calibration with Unknown Through
 TRL initiates a Through-Reflect-Line calibration
 NIST Multiline TRL initiates a NIST Multiline TRL calibration
 TRM initiates a Through-Reflect-Match calibration
 TOM initiates a Through-Open-Match calibration
 TNA initiates a Through-Network-Attenuation calibration
 Normalize Forward and Normalize Reverse initiate a normalization in forward and reverse
direction, respectively. The normalization uses a through standard, however, only one direction is
normalized.
Use Start Cal – Other... to set up and perform other two-port calibrations .
Remote
control:
[SENSe<Ch>:]CORRection:COLLect:AUTO ' ', <port_no> (for matching analyzer
and cal unit ports)
[SENSe<Ch>:]CORRection:COLLect:AUTO:PORTs (for arbitrary pairs of ports)
[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine "<cal_name>", FRTRans |
OPTPort | TOSM | UOSM | TRL | NMTRl | TRM | TOM | TNA | FTRans |
RTRans, <port_no>,<port_no>
Three- or Four-Port Calibrations
Three-Port P1 P2 P3, Three-Port P1 P2 P4 and Four-Port P1 ... P4 open a submenu to select and
perform a calibration at the respective test ports. The submenu structure is identical for all three
submenus:
