Raymarine LIGHTHOUSE 3 User Manual

1. Piloticon—With Autopilotcontrolenabled,thePiloticonisdisplayedonscreen;selectingthe
icondisplaysthePilotsidebar.WhentheAutopilotisengagedthePiloticonisreplacedwith
theDisengagepiloticon.
2.Pilotsidebar—ThePilotsidebarprovidescontrolsandinformationrelatingtoyourautopilot
system.WiththeAutopilotengagedthePilotsidebar’scontentisexpandedtoprovidefurther
controlsandinformation.ThePilotsidebarcanbehiddenbyswipingthesidebartotheleft.
Thesidebarcanbedisplayedagainbyswipingfromtheleftofthescreentowardsthecenter
ofthescreen.
Engagingtheautopilot—Lockedheading
WithAutopilotcontrolenabled:
1.ForWheelandTillerpilots,engagethemechanicaldrivebyeitherengagingthewheeldrive’s
clutchorattachingthepushrodontothetillerpin.
2.Selectthe
Autopiloticon.
ThePilotsidebarisdisplayed.
3.Select SteertoHdg.
4.Select
Engagepilot.
Engagingtheautopilot—Navigation
WithAutopilotcontrolenabled:
1.ForWheelandTillerpilots,engagethemechanicaldrivebyeitherengagingthewheeldrive’s
clutchorattachingthepushrodontothetillerpin.
2.InitiateaGotoorFollowfromthechartapp.
3.Selectthe
Autopiloticon.
ThePilotsidebarisdisplayed.
4.Select
SteertoNav.
5.Selecteither
Engagepilotorifacrosstrackerrorexiststhenselect ALONGroutelegor DIRECT
fromhere.
Selecting ALONG ALONG
ALONG
route route
route
leg leg
leg
willsteeralongtheoriginaltrack.
Selecting DIRECT DIRECT
DIRECT
from from
from
here here
here
willplotanewtrackfromyourcurrentpositiontothedestination.
A utopilotcontrol
103

Raymarine LIGHTHOUSE 3 Specifications

General

Operating System	LightHouse 3
Networking	RayNet (Ethernet), NMEA2000
Display	High-resolution touchscreen
User Interface	Touchscreen with intuitive interface
Navigation	Advanced navigation features
Radar Support	Yes
Sonar Support	Yes
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Integration	Engine data, autopilot control, digital switching, entertainment systems
GPS	Built-in GPS receiver
Cartography	Supports Navionics and LightHouse charts
AIS Compatibility	Yes
Compatible Displays	Raymarine Axiom, Axiom Pro, Axiom XL
Chart Support	Navionics, C-MAP, LightHouse charts
Radar Compatibility	Raymarine Quantum
Sonar Compatibility	Raymarine CP370, CP470, CP570 sonar modules
Software Updates	Via Wi-Fi or microSD card
