Raymarine LIGHTHOUSE 3 - Searching a PDF

To Next Page

To Previous Page

.4SearchingaPDF

Y oucansearchaPDFdocumentforawordorphraseusingtheFindfunction.

WiththePDFdisplayedintheviewer:

1.Select Find.

2.Enterthewordorsearchterm.

3.Select

FIND.

Thedocumentwillscrolltotheﬁrstoccurrenceofthesearchedterm,whichwillbehighlighted.Use

theRightarrowand Leftarrowcontrolstocycletothepreviousornextoccurrenceofthesearch

term.Y oucanalsosearchforanothertermbyselecting Findandenteringanewterm,oryoucan

canceltheﬁndfunctionbyselectingCancel.
