Datamaster
S
ystemscontainingmorethanoneMFDmusthaveadesignatedDatamasterMFD.TheData
masteristheprimaryMFDinthenetwork,andshouldbetheMFDthatisphysicallyconnectedto
theSeaTalkng®/NMEA2000CANbusnetwork,andanyotherdevicesandsourcesofdatain
yoursystem.TheDatamasterbridgesthedataovertheSeaTalkhs™networktoanycompatible
networked‘repeater’MFDs.
InformationsharedbytheDatamasterincludes:
•Cartography
•Waypoints,RoutesandTracks
•Radar
•Sonar
•Datareceivedfromtheautopilot,GNSS(GPS)receiver,instruments,transducers,theengine
andanyothercompatibleexternalsources.
Note:Y oursystemmaybewiredforredundancywithdataconnectionsmadetorepeatdisplays.
Howevertheseconnectionswillonlybecomeactiveintheeventofafaultand/orreassignmentof
thedatamaster.
S witchingDataMaster
Y oucanswitchtheMFDyouwanttobetheDatamasteratanytime.
FromtheNetworktab: Homescreen>Settings>Network:
1.Fromthelist,selecttheMFDyouwanttodesignateasthenewDatamaster.
2.Select
AssignasDataMasterfromthepop-overoptions.
SharedBrightness
Sharedbrightnessenablessimultaneousbrightnessadjustmentofallproductsthatarepartof
thesamegroup.
Thefollowingproductsarecompatiblewithsharedbrightness:
•LightHouse™3MFDsusingsoftwareversion3.4orgreater.
•LightHouse™orLightHouse™2poweredMFDs.
•SeaTalkng®InstrumentdisplaysandPilotcontrollers.
•SeaTalkng®VHFDSCRadios.
•RMK-9andRMK-10remotebuttonpads.
Anyadjustmentstothesharedbrightnesslevelwillbeappliedtoallproductsassignedtothesame
group.
Homescreen89

Raymarine LIGHTHOUSE 3 Specifications

General

Operating System	LightHouse 3
Networking	RayNet (Ethernet), NMEA2000
Display	High-resolution touchscreen
User Interface	Touchscreen with intuitive interface
Navigation	Advanced navigation features
Radar Support	Yes
Sonar Support	Yes
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Integration	Engine data, autopilot control, digital switching, entertainment systems
GPS	Built-in GPS receiver
Cartography	Supports Navionics and LightHouse charts
AIS Compatibility	Yes
Compatible Displays	Raymarine Axiom, Axiom Pro, Axiom XL
Chart Support	Navionics, C-MAP, LightHouse charts
Radar Compatibility	Raymarine Quantum
Sonar Compatibility	Raymarine CP370, CP470, CP570 sonar modules
Software Updates	Via Wi-Fi or microSD card
