14.
1Yamahaenginegatewayselection
WhentheMFDisconnectedtoY amahaenginesviaacompatiblegateway/interface,enginerelated
datacanbedisplayedinthededicatedY amahaapp.
EnginegatewayselectionisperformedaspartoftheBoatdetailssettingsintheinitialMFDstartup
wizard.TheselectioncanalsobechangedintheBoatdetailssettingstab:
Homescreen>Settings>
Boatdetails>Enginemanufacturer.
Ifyouhaveacompatiblegatewayinterface
,select
Y
amahafromtheEnginemanufactureroptions.
IfyouhaveacompatiblegatewaythatincludestheY amahaMFDHDMIinterface,select
Y
amaha
HDMIfromtheEnginemanufactureroptions.
CompatibleY
amahagateways
Thefollowinggatewaysarecompatible:
TheYamahaappiscompatiblewithY amahaCommandLinkandCommandLinkProwhen
connectedtotheMFDviaaY amahaNMEA2000gatewayorCL7gauge.
TheYamahaHDMIappiscompatiblewithYamahaCommandLinkandCommandLinkProwhen
connectedtotheMFDviaaY amahaHelmMasterEX6YGgatewayandMFDinterface(MFDI).
14.2YamahaHDMIoverview
TheMFDwilldisplaytheHDMIvideoinputfeedfromtheY amahaMFDI.Controlisachievedusing
theY amahasuppliedhandheldcontroller.
PleaserefertothedocumentationthatwassuppliedwithyourY amahaenginesystem.
14.3Yamahaappoverview
The
YamahaappenablesyoutoviewenginesystemdatafromaconnectedY amahaCommand
LinkorCommandLinkPronetwork.
Note:
TheY amahaappwillonlydisplaydatawhenacompatibleY amahaCommandLinkorCommand
LinkPronetworkisconnectedtotheMFDviaaY amahaNMEA2000gatewayorCL7gauge.
TheY amahaappcanonlybedisplayedasaFullscreenapppage.
TheYamahaappispre-configuredwithanumberofcustomizabledatapages.
ForeachinstanceoftheYamahaappyoucanselectwhichDatapagesyouwanttouse;the
Datapageselectionwillpersistoverapowercycle.
