Raymarine LIGHTHOUSE 3 User Manual

P
ossiblecausesPossiblesolutions
•Anonymousloginshouldbeenabled.
T
oomanyIPfeedson
network.
DisplayingmultiplefeedsonmultipleMFDssimultaneouslymay
causesomefeedstonotbedisplayed.Tryviewinglessfeeds.
Problemwiththecamera
connections.
1.Checktheunit’
sconnectorforbrokenorbentpins.
2.Checkthatthecableconnectorisfullyinsertedintotheunit
andthatthelockingcollarisinthelockedposition.
3.Checkthecableandconnectorsforsignsofdamageor
corrosion,replaceifnecessary.
4.Withtheunitturnedon,tryflexingthepowercabletoseeifthis
causestheunittore-boot/loosepower,replaceifnecessary.
Problemwithpowersupply
tothecameraorthermal
camera ’sJCU(ifusedasthe
primarycontroller)
•Checkthepowerconnectionstothecamera,JCU,andPoE
injector(ifused).
•Ensurethatthepowerswitch/breakerison.
•Checkthefuse/breakerstate.
CameraisinS tandbymode.
Usethecameracontrols(eithertheCameraapporaThermal
camera’sJCU)to“wake”thecamerafromstandby.
PTZcameras—Erraticorunresponsivecontrols
P ossiblecausesPossiblesolutions
Networkproblem.
•Checkthatthecontrollerandcameraarecorrectlyconnected
tothenetwork.
•Ifused,checkthestatusofthenetworkswitch.
•CheckthatR ayNetcablesarefreefromdamage.
Controlconflict,e .g.caused
bymultipleusersatdifferent
stations.
Ensurethatnoothercontrollersareinuseatthesametime.
Problemwiththecontroller .
•Checkpower/networkcablingtothecontrollerandPoEinjector,
ifused.
•Checkothercontrollers,ifavailable.
Cannotswitchbetweencamerafeeds
P ossiblecausesPossiblesolutions
Cameraisnotadualpayload
model.
Only“dualpayload”(duallens)camerassupportfeedswitching.
Noisyimage
P ossiblecausesPossiblesolutions
P oorqualityorfaultycabling.
•Ensurecablerunsarenolongerthantheyneedtobe.
•Useonlyhighqualityshieldedcablesuitableforthemarine
environment.
Cableispickingup
electromagneticinterference
(EMI)fromanotherdevice
.
•Ensureyouareusingahighqualityshieldedcable.
•Ensurepropercableseparation,forexampledonotrundataand
powercablesincloseproximitywitheachother.
•Incertainconditionsitmaybenecessarytofitsuppression
ferritestocablingtoeliminateinterference.
T roubleshooting
413

Raymarine LIGHTHOUSE 3 Specifications

General

Operating System	LightHouse 3
Networking	RayNet (Ethernet), NMEA2000
Display	High-resolution touchscreen
User Interface	Touchscreen with intuitive interface
Navigation	Advanced navigation features
Radar Support	Yes
Sonar Support	Yes
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Integration	Engine data, autopilot control, digital switching, entertainment systems
GPS	Built-in GPS receiver
Cartography	Supports Navionics and LightHouse charts
AIS Compatibility	Yes
Compatible Displays	Raymarine Axiom, Axiom Pro, Axiom XL
Chart Support	Navionics, C-MAP, LightHouse charts
Radar Compatibility	Raymarine Quantum
Sonar Compatibility	Raymarine CP370, CP470, CP570 sonar modules
Software Updates	Via Wi-Fi or microSD card
