8.9R
ealBathy™
Y oucancreateprecisepersonalbathymetricchartsinrealtimeusingRaymarine’sRealBathy™feature.
WhenusingtheRealBathy™feature,newcontourlinesaredrawninrealtimeonthescreenbasedon
yourtransducer’sdepthreadings.Colorshadingisusedtoreflectdepth,withthedarkestshades
signifyingtheshallowestarea.Thesonardataisrecordedtotheinsertedmemorycard.
R equirements
TheRealbathyfeaturerequiresthefollowing:
•LightHouse™softwareversion3.9orlater.
•LightHouse™vectorbasedcharts,thatincludetidestationinformationforthelocationyouwish
tosurvey.
•MicroSDcardwithsufficientfreespacetorecorddepthandbathymetrydata.
•Y oumustascertainthedistanceabovethebottomfaceofyourdepthtransducertothewaterline,
asshowninthefollowingillustration:
1.W aterline.
2.Waterdepthbelowtransducerface.
170

Raymarine LIGHTHOUSE 3 Specifications

General

Operating System	LightHouse 3
Networking	RayNet (Ethernet), NMEA2000
Display	High-resolution touchscreen
User Interface	Touchscreen with intuitive interface
Navigation	Advanced navigation features
Radar Support	Yes
Sonar Support	Yes
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Integration	Engine data, autopilot control, digital switching, entertainment systems
GPS	Built-in GPS receiver
Cartography	Supports Navionics and LightHouse charts
AIS Compatibility	Yes
Compatible Displays	Raymarine Axiom, Axiom Pro, Axiom XL
Chart Support	Navionics, C-MAP, LightHouse charts
Radar Compatibility	Raymarine Quantum
Sonar Compatibility	Raymarine CP370, CP470, CP570 sonar modules
Software Updates	Via Wi-Fi or microSD card
