Raymarine LIGHTHOUSE 3 User Manual

1.Norudderdatafound.
2.Rudderdeflectiontoport.
3.Rudderdeflectiontostarboard.
3.3Dataoverlays
S
ystemdatacanbeoverlaidontotheChart,Radar,SonarorCameraapps.SomeappshaveData
overlaysenabledbydefault.
Dataoverlayscanbeplacedanywhereontheapppageandcanbeplacedoveranyappina
Splitscreenapppage .
Dataoverlayscanbecustomizedfrom: Menu>Settings>PageSettings>Editdataoverlays.
Ineditmode,dragthedataoverlaytothedesiredlocation.TouchandholdaDataoverlaytodisplay
thepop-overmenu,whereyoucan Edit, Move, Resizeor DeletetheDataoverlay.
Select Addtoaddanotheroverlayor Donetoexiteditmode.
DataoverlayandSidebardataitems
ThefollowingdataitemsareavailablefordisplayintheDashboardapp,inDataoverlaysand
Sidebars.
Note:
Fordatatobeavailablecompatiblesensorsandtransducersarerequiredtobeconnectedtot
hesamedatanetworkastheMFD .
Generalinformation29

Raymarine LIGHTHOUSE 3 Specifications

General

Operating System	LightHouse 3
Networking	RayNet (Ethernet), NMEA2000
Display	High-resolution touchscreen
User Interface	Touchscreen with intuitive interface
Navigation	Advanced navigation features
Radar Support	Yes
Sonar Support	Yes
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Integration	Engine data, autopilot control, digital switching, entertainment systems
GPS	Built-in GPS receiver
Cartography	Supports Navionics and LightHouse charts
AIS Compatibility	Yes
Compatible Displays	Raymarine Axiom, Axiom Pro, Axiom XL
Chart Support	Navionics, C-MAP, LightHouse charts
Radar Compatibility	Raymarine Quantum
Sonar Compatibility	Raymarine CP370, CP470, CP570 sonar modules
Software Updates	Via Wi-Fi or microSD card
