Raymarine LIGHTHOUSE 3 User Manual

1
Currentreading:
ThecurrentheadingreportedbytheAR200.
2
Maximumdeviationatlastcalibration:
Themaximumdeviationreportedduringthelastlinearizationprocess.
Important:
•Ifthe Maximumdeviationatlastcalibrationis45°orabove,itisrecommended
thattheAR200unitismovedandre-installedinalocationwhichissubjectto
lessmagneticinterference.
Calibrationinprogress:
Whilelinearizationisinprogresstheprogresspercentageisdisplayed.
3 Compassoffset
Oncethelinearizationprocesshascompleted,itispossiblethattheheadingvalue
maybeslightlyoutofalignment.Thisiscommonwhereinstallationspaceislimited
andtheAR200isnotproperlyalignedwithyourvessel’
slongitudinalaxis.Inthis
case,itispossibletomanuallyadjusttheCompassoffset.
4
Compasslock
Whenenabled,theCompasslockpreventsthecontinualmonitoringandadaptation
ofthecompasslinearizationprocess.Formoreinformation,referto:Compasslock.
5
Resetcalibration
Y oucanresetyourAR200’scurrentlinearizationsettingsbyselecting
Reset
calibration
Continualmonitoringandadaptation
T oensureoptimumperformance,aftertheinitiallinearizationprocessiscompletetheunitcontinues
tomonitorandadaptthecompasslinearizationtosuitcurrentconditions.
Iftheconditionsforlinearizationarelessthanideal,theautomaticlinearizationprocesstemporarily
pausesuntilconditionsimproveagain.Thefollowingconditionscancausethelinearizationprocess
totemporarilypause:
•significantmagneticinterferenceispresent
•vesselspeedtooslowortoofast
ClearCruise(ObjectDetection/VideoAnalytics,and
A ugmentedReality)
353

Raymarine LIGHTHOUSE 3 Specifications
