1
CancelFishOn/ CancelCircleme
Selecting
CancelFishOn/ CancelCirclemewillstopFishOn/Circlememodeand
theU
AVwillhoverinitscurrentlocation.Ifrequiredyoucanmanuallystoprecording
byselectingthe
S
topicon.
2
U
AVicon
TheUAViconcanbedisplayedintheChartapp.Theiconincludesacameraheading
graphic,aCourseOverGround(COG)vectorandalinelinkingyourvesselicon
toyourUAVicon.
3
Virtualjoystick
InFishOn/Circlememodetheleftvirtualjoystickprovides
Upand Downcontrolsto
adjusttheUAV’sdistancefromyourvessel.
4
Rotation
TheRotationslidercontrolisusedtoadjusttheUAV’sdirectionofrotationandrotation
speed.WiththecontrolontheslidercenterlinetheUAVwillmaintainpositionin
relationtoyourvessel.Movingthesliderrightoftheslidercenterlinerotatesthe
UAVcounter-clockwiseandmovingtheslidercontroltotheleftofthecenterline
rotatestheUAVclockwise.Thefartherleftorrighttheslidercontrolissetthefaster
therotationspeedwillbe.
5
Virtualjoystick
InFishOn/Circlememodetherightvirtualjoystickprovides Forwardand Backwards
controlstoadjusttheUAV’sheightfromyourvessel.
Note:
DuringyourinitialMFDconfigurationtheboating Activityyouselectedwilldeterminewhether
thefunctionislabelledFishonor Circleme.IfFishing(freshwater),Fishing(saltwater)or
Retail/demonstrationisselectedthenthefunctionislabelled Fishon,otherwisethefunction
islabelled
Circleme.
20 .13UAVChartintegration
WhenacompatibleUAVwithaGNSS(GPS)positionfixisconnectedtoyourMFD,aUAVicon
representingthepositionoftheUAVisdisplayedintheChartapp.
384
