12.8R
adartargets
WithacompatibleRadarscannerconnectedtoyourMFD,radartargetscanbetrackedintheChart
appandRadarapp.DependingonyourRadarscanner,radartargetscanbeacquiredmanuallyor
automatically,basedonyourconfigured
Guardzones.
T
rackedradartargetsareidentifiedonscreenusingtargetsymbols.
Multipleradartargetscanbetrack edsimultaneously.
Targetvectorsandinformationcanbedisplayedforeachtarget.
RadartargetoptionsareavailablefromtheRadartargetcontextmenu.TheRadartargetcontext
menuprovidesoptionsforyouto Canceltarget, ShowCPAgraphicordisplay Targetinfoonscreen
byselectingtherelevantoption.TheRadarcontextmenuisaccessedbyselectingtheradartarget.
Radartargetacquisitiondatasourcerequirements
Radartargetacquisitionrequiresthefollowingdatasourcestobeavailableonyoursystem(e.g.
connectedtoyourmultifunctiondisplay,viaSeaTalkng®orNMEA0183).
DatatypeExampledatasource
COG(CourseOverGround)GPSorGNSSreceiver(MFDinternalreceiveror
e xternalreceiver).
SOG(SpeedOverGround)GPSorGNSSreceiver(MFDinternalreceiveror
e xternalreceiver).
HDG/HD T(TrueHeading)
CompassorAutopilotsensorproviding
Fastheadingdata(e.g.EvolutionEV-1/EV-2).
R adartargets
RadartargetsymbolsareusedtoidentifyRadartargetsonscreen.
RadartargetsaredisplayedintheRadarappandwhenRadaroverlayisenabled( Chartapp>Menu
>T argets>Radarsettings>RADAROVERLAY>Showradaroverlay)theyarealsodisplayed
intheChartapp.
R adarapp
273
