Acquiringtarget
(manual)—Thin
dashedGreencircle
Acquiredtarget
(manual)—Green
circlewithT
argetID
Acquiringtarget(auto)
—ThickdashedRed
circle,flashesuntil
acknowledged
Unacknowledged
acquiredtarget(auto)
—Redcircle,flashes
untilacknowledged
Dangeroustarget
—Redcirclewith
TargetID,flashesuntil
acknowledged
Losttarget(Targetnot
detectedfor4Radar
scans)—Graycircle
withRedcrossthrough
Onceacquiredthetarget’ sCOG(CourseOverGround)andSOG(SpeedOverGround)canbe
displayedbelowthetargetID.
TheTargetinfoiscoloredBlueifCOGandSOGvaluesareTrueorOrangeifvaluesareRelative.
TargetinfowillturnRedifthetargetbecomesdangerous.
Acquiringatargetmanually
ToacquireaRadartargetmanuallyusingMARPA(MiniAutomaticRadarPlottingAid)followthe
stepsbelow.
WiththeRadaroverlayenabled:
1.Selecttheobject/target.
Thecontextmenuisdisplayed.
2.Select moreoptions.
3.SelectAcquiretarget.
Onceacquiredthetargetwillbetracked.
Accessingtargetoptions
Targetspecificoptionsareavailablefortargetsthatarecurrentlybeingtracked.Thetargetoptions
canbeaccessedfromthetarget’scontextmenuandfromthePop-overoptionsintherelevanttarget
list.Theoptionsavailablearedependentonthetypeoftarget.
Toaccessatarget’scontextmenu:
•Pressandholdonthetargetonscreen,or
•Highlightthetargetonscreenusingthe Directioncontrolsandpressthe OKbutton.
