RL78/G1H CHAPTER 7 TIMER ARRAY UNIT
R01UH0575EJ0120 Rev. 1.20 Page 201 of 920
Dec 22, 2016
Figure 7 - 49 Example of Set Contents of Registers in External Event Counter Mode (1/2)
(a) Timer mode register mn (TMRmn)
(b) Timer output register m (TOm)
(c) Timer output enable register m (TOEm)
(d) Timer output level register m (TOLm)
(e) Timer output mode register m (TOMm)
Note TMRm2: MASTERmn bit
TMRm1, TMRm3 SPLITmn bit
TMRm0: Fixed to 0
Remark m: Unit number (m = 0), n: Channel number (n = 3)
1514131211109876543210
TMRmn
CKSmn1
1/0
CKSmn0
1/0 0
C
CSmn
1
M/S
Note
0/1
S
TSmn2
0
STSmn1
0
S
TSmn0
0
CISmn1
1/0
CISmn0
1/0 0 0
MDmn3
0
M
Dmn2
1
M
Dmn1
1
MD
mn0
0
Operation mode of channel n
011B Event count mode
Setting of operation when counting is started
0: Neither generates INTTMmn nor inverts
timer output when counting is started.
Selection of TImn pin input edge
00B: Detects falling edge.
01B: Detects rising edge.
10B: Detects both edges.
11B: Setting prohibited
Start trigger selection
000B: Selects only software start.
Setting of MASTERmn bit (channel 2)
0: Independent channel operation function.
Setting of SPLITmn bit (channels 1, 3)
0: 16-bit timer mode
1: 8-bit timer mode
Count clock selection
1: Selects the TImn pin input valid edge.
Operation clock (f
MCK) selection
00B: Selects CKm0 as operation clock of channel n.
10B: Selects CKm1 as operation clock of channel n.
01B: Selects CKm2 as operation clock of channels 1, 3 (This can only be selected using channels 1 and 3 in the 8-bit timer mode).
11B: Selects CKm3 as operation clock of channels 1, 3 (This can only be selected using channels 1 and 3 in the 8-bit timer mode).
Bit n
TOm
TOmn
0
0: Outputs 0 from TOmn
Bit n
TOEm
TO
Emn
0
0: Stops the TOmn output operation by counting operation.
Bit n
TOLm
T
OLmn
0
0: Cleared to 0 when TOMmn = 0 (master channel output mode).
Bit n
TOMm
T
OMmn
0
0: Sets master channel output mode.
To Next Page
