RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 706 of 920
Dec 22, 2016
Table 19 - 1 Interrupt Source List (1/2)
Note 1. The default priority determines the sequence of interrupts if two or more maskable interrupts occur simultaneously.
Zero indicates the highest priority and 44 indicates the lowest priority.
Note 2. Basic configuration types (A) to (C) correspond to (A) to (C) in Figure 19 - 1.
Note 3. When bit 7 (WDTINT) of the option byte (000C0H) is set to 1.
Note 4. When bit 7 (LVIMD) of the voltage detection level register (LVIS) is cleared to 0.
Interrupt Type
Default Priority
Note 1
Interrupt Source
Internal/External
Vector Table Address
Basic Configuration Type
Note 2
Name Trigger
Maskable
0
INTWDTI
Watchdog timer interval
Note 3
(75% of overflow time + 1/2 fIL)
Internal
0004H
(A)
1
INTLVI
Voltage detection
Note 4
0006H
2 INTP0 Pin input edge detection
External 0008H (B)
5INTP3
Internal 000EH
6INTP4
External 0010H
8 INTCSI20 CSI20 transfer end or buffer empty interrupt
Internal
0014H (A)
9 INTCSI21 CSI21 transfer end or buffer empty interrupt 0016H
10
INTTM11H End of timer channel 11 count or capture
(at higher 8-bit timer operation)
0018H
13
INTTM01H End of timer channel 01 count or capture
(at higher 8-bit timer operation)
0022H
14
INTST1/
INTCSI10
UART1 transmission transfer end or buffer empty interrupt/CSI10
transfer end or buffer empty interrupt
0024H
15 INTSR1 UART1 reception transfer end 0026H
16
INTSRE1 UART1 reception communication error occurrence
0028H
INTTM03H End of timer channel 03 count or capture
(at higher 8-bit timer operation)
17 INTIICA0 End of IICA0 communication 002AH
18 INTTM00 End of timer channel 00 count or capture 002CH
19 INTTM01 End of timer channel 01 count or capture 002EH
20 INTTM02 End of timer channel 02 count or capture 0030H
21 INTTM03 End of timer channel 03 count or capture 0032H
22 INTAD End of A/D conversion 0034H
23 INTRTC Fixed-cycle signal of real-time clock/alarm match detection 0036H
24 INTIT Interval signal detection 0038H
26
INTST3/
INTCSI30
UART3 transmission transfer end or buffer empty interrupt/CSI30
transfer end or buffer empty interrupt
003CH
27 INTSR3 UART3 reception transfer end 003EH
28 INTTRJ0 Timer RJ interrupt 0040H
