RL78/G1H CHAPTER 4 CPU ARCHITECTURE
R01UH0575EJ0120 Rev. 1.20 Page 60 of 920
Dec 22, 2016
Note 1. The value after a reset is adjusted at the time of shipment.
Note 2. The value after a reset is a value set in FRQSEL2 to FRQSEL0 of the option byte (000C2H).
Table 4 - 10 Extended Special Function Register (2nd SFR) List (1/7)
Address
Extended Special Function Register
(2nd SFR) Name
Symbol R/W
Manipulable Bit Range
After Reset
1-bit 8-bit 16-bit
F0010H A/D converter mode register 2 ADM2 R/W
√√— 00H
F0011H Conversion result comparison upper limit
setting register
ADUL R/W —
√ —FFH
F0012H Conversion result comparison lower limit
setting register
ADLL R/W —
√ — 00H
F0013H A/D test register ADTES R/W —
√ — 00H
F0030H Pull-up resistor option register 0 PU0 R/W
√√— 00H
F0031H Pull-up resistor option register 1 PU1 R/W
√√— 00H
F0033H Pull-up resistor option register 3 PU3 R/W
√√— 00H
F0034H Pull-up resistor option register 4 PU4 R/W
√√— 01H
F0037H Pull-up resistor option register 7 PU7 R/W
√√— 00H
F0038H Pull-up resistor option register 8 PU8 R/W
√√— 00H
F003AH Pull-up resistor option register 10 PU10 R/W
√√— 00H
F003CH Pull-up resistor option register 12 PU12 R/W
√√— 00H
F003EH Pull-up resistor option register 14 PU14 R/W
√√— 00H
F0040H Port input mode register 0 PIM0 R/W
√√— 00H
F0048H Port input mode register 8 PIM8 R/W
√√— 00H
F004EH Port input mode register 14 PIM14 R/W
√√— 00H
F0050H Port output mode register 0 POM0 R/W
√√— 00H
F0057H Port output mode register 7 POM7 R/W
√√— 00H
F0058H Port output mode register 8 POM8 R/W
√√— 00H
F005EH Port output mode register 14 POM14 R/W
√√— 00H
F0060H
Port mode control register 0 PMC0
R/W
√√—FFH
F006AH
Port mode control register 10 PMC10
R/W
√√—FFH
F006CH
Port mode control register 12 PMC12
R/W
√√—FFH
F006EH
Port mode control register 14 PMC14
R/W
√√—FFH
F0070H
Noise filter enable register 0 NFEN0
R/W
√√— 00H
F0071H
Noise filter enable register 1 NFEN1
R/W
√√— 00H
F0074H
Timer input select register 0 TIS0
R/W —
√ — 00H
F0076H
A/D port configuration register ADPC
R/W —
√ — 00H
F0078H Invalid memory access detection control
register
IAWCTL R/W —
√ — 00H
F007AH
Peripheral enable register 1 PER1
R/W
√√— 00H
F007BH
Port mode select register PMS
R/W
√√— 00H
F0090H
Data flash control register DFLCTL
R/W
√√— 00H
F00A0H High-speed on-chip oscillator trimming register HIOTRM R/W —
√ — Undefined
Note 1
F00A8H High-speed on-chip oscillator frequency select
register
HOCODIV R/W — √ — Undefined
Note 2
To Next Page
