RL78/G1H CHAPTER 24 SAFETY FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 777 of 920
Dec 22, 2016
24.3.1.1 Flash memory CRC control register (CRC0CTL)
This register is used to control the operation of the high-speed CRC ALU, as well as to specify the operation range.
The CRC0CTL register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 24 - 1 Format of Flash memory CRC control register (CRC0CTL)
Remark Input the expected CRC operation result value to be used for comparison in the lowest 4 bytes of the flash
memory. Note that the operation range will thereby be reduced by 4 bytes.
Address: F02F0H After reset:00H R/W
Symbol<7>6543210
CRC0CTL CRC0EN 0 FEA5 FEA4 FEA3 FEA2 FEA1 FEA0
CRC0EN Control of high-speed CRC ALU operation
0 Stop the operation.
1 Start the operation according to HALT instruction execution.
FEA5 FEA4 FEA3 FEA2 FEA1 FEA0 High-speed CRC operation range
00000000000H to 03FFBH (16 K - 4 bytes)
00000100000H to 07FFBH (32 K - 4 bytes)
00001000000H to 0BFFBH (48K - 4 bytes)
00001100000H to 0FFFBH (64K - 4 bytes)
00010000000H to 13FFBH (80K - 4 bytes)
00010100000H to 17FFBH (96K - 4 bytes)
00011000000H to 1BFFBH (112K - 4 bytes)
00011100000H to 1FFFBH (128K - 4 bytes)
00100000000H to 23FFBH (144K - 4 bytes)
00100100000H to 27FFBH (160K - 4 bytes)
00101000000H to 2BFFBH (176K - 4 bytes)
00101100000H to 2FFFBH (192K - 4 bytes)
00110000000H to 33FFBH (208K - 4 bytes)
00110100000H to 37FFBH (224K - 4 bytes)
00111000000H to 3BFFBH (240K - 4 bytes)
00111100000H to 3FFFBH (256K - 4 bytes)
010000
00000H to 43FFBH (272 K-4
bytes)
010001
00000H to 47FFBH (288 K-4
bytes)
010010
00000H to 4BFFBH (304 K-4
bytes)
010011
00000H to 4FFFBH (320 K-4
bytes)
010100
00000H to 53FFBH (336 K-4
bytes)
010101
00000H to 57FFBH (352 K-4
bytes)
010110
00000H to 5BFFBH (368 K-4
bytes)
010111
00000H to 5FFFBH (384 K-4
bytes)
011000
00000H to 63FFBH (400 K-4
bytes)
011001
00000H to 67FFBH (416 K-4
bytes)
011010
00000H to 6BFFBH (432 K-4
bytes)
011011
00000H to 6FFFBH (448 K-4
bytes)
011100
00000H to 73FFBH (464 K-4
bytes)
011101
00000H to 77FFBH (480 K-4
bytes)
011110
00000H to 7BFFBH (496 K-4
bytes)
011111
00000H to 7FFFBH (512 K-4
bytes)
Other than the above Setting prohibited
