213Basic Procedure for Wipe Settings
Chapter 5 Wipes
a) The patterns are the same as for a standard wipe. See “Wipe Pattern List” (page 363).
If you selected Pattern, you can also carry out the pattern selection by
pressing the [Mix Ptn Select] button in the Matte Adjust menu, to display
the Mix Ptn Select menu. Select any pattern appearing in the Mix Ptn
Select menu (wipe patterns 1 to 24) by pressing the appropriate button, and
you can then adjust the following parameters.
5
If you selected Pattern in step 4, if required, the following modifiers can
be added. After selecting a wipe mix, skip to step 6.
• When turning [Position] on and setting the pattern position
a) See page 214.
• When turning [Multi] on and using replications of the same pattern
a) See page 219.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 218.
3 Pattern Pattern number
1 to 24
a)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally
1 to 63
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
To Next Page
