WEILER E2850 REMIXING TRANSFER VEHICLE
5-20
Maintenance
5
Maintenance Procedures
Storage Conveyor Chain - Adjust Tension/Uneven Sag
1. With engine off and ignition key removed, adjust
chain until bottom of chain slat is 2" (51 mm) at
measurement position shown in detail view B,
5-19.
Adjust both sides of chain until chain sag is even
from side to side, +/- 1/4" (6 mm).
•To tighten chain, loosen nut (1), adjust nut (2), then
tighten nut (1).
•To loosen chain, loosen nut (2), adjust nut (1), then
tighten nut (2).
2. Clean material off of cleanout door and sealing edges to allow door to close tightly.
3. Start engine. Close and latch cleanout door. Verify door is fully closed. Turn engine off.
Slipping and falling off machine can result in death or serious injury.
Adjust chain tension while standing on a securely placed ladder. Never
climb onto top of machine to access adjusters.
