WEILER E2850 REMIXING TRANSFER VEHICLE
2-9
Machine Controls
2
Machine Controls
Right Control Panel
(1) Propel Lever
Pull up on latch ring to move propel lever out of neutral.
(2) Propel Speed Dial
(3) Windrow Float Switch (Optional)
(4) Float Indicator Lamp
Illuminates when Windrow Float is on.
(5) Hopper Baffle Switch
Push lever away from operator to move
forward.
Center lever to place ground drive in neutral.
Pull lever toward operator to move in reverse.
Turn CW to increase ground speed.
Turn CCW to decrease ground speed.
Push up to turn float on.
Push down to turn float off.
Push up to open hopper baffle.
Push down to close hopper baffle.
1
2
3
4
5
