WEILER E2850 REMIXING TRANSFER VEHICLE
5-42
Maintenance
5
Maintenance Procedures
(1) Caster Sleeves - Grease (Windrow Only)
Four shots - two fittings (one fitting each caster
sleeve)
(2) Caster Wheel Axles - Grease
Four shots - two fittings each caster wheel axle.
(3) Caster Wheel Pivots - Grease
Two shots - two fittings, each caster wheel pivot.
(4) Clutch Operating Shaft - Grease
Two shots - two fittings (one fitting under each end
of operating shaft).
(5) Discharge Conveyor Frame Pivot Lower -
Grease
Ten shots - one fitting on lower pivot frame
1
2
3
4
5
