WEILER E2850 REMIXING TRANSFER VEHICLE
2-26
Machine Controls
2
Machine Controls
Storage Hopper Management System (Optional)
Storage hopper management system measures the amount of asphalt in the storage hopper. One LED
light bar is located on each side of operator platform.
(1) Storage Hopper Level Sensor
Detects level of asphalt in storage hopper. May be
equipped with optional vandal cover (A).
(2) Storage Hopper LED Light Bars
Storage hopper LED light bars indicate the level of
material in the storage hopper.
• Top Red Lamp - Flashing > 95%
• Top Red Lamp - Solid > 80%
• Middle Green Lamp - Flashing > 60%
• Middle Green Lamp - Solid > 40%
• Lower Red Lamp - Flashing > 20%
• Lower Red Lamp - Solid < 20%
