Weiler E2850 - Storage Conveyor Sprockets; Discharge Conveyor Sprockets

WEILER E2850 REMIXING TRANSFER VEHICLE
5-57
Maintenance
5
Maintenance Procedures
Storage Conveyor Sprockets
1. Open both storage conveyor cleanout doors (1) to
access footshaft sprockets (2).
2. Turn engine off.
3. Unbolt and open both headshaft inspection doors
(2).
4. Perform sprocket inspection.
Discharge Conveyor Sprockets
1. Completely lower discharge conveyor.
2. Turn engine off.
3. Perform sprocket inspection.
1
2
2
