WEILER E2850 REMIXING TRANSFER VEHICLE
5-37
Maintenance
5
Maintenance Procedures
(1) Clutch Throw-Out Collar - Grease
Two shots - one fitting.
(2) Discharge Conveyor Footshaft Bearings -
Grease
Twelve shots - two fittings (one fitting on each side).
(3) Discharge Conveyor Headshaft Bearing -
Grease
Twelve shots - one fitting, right side.
(4) Discharge Conveyor Idler Bearings - Grease
Five shots - 8 fittings (four on each side of conveyor).
1
2
3
4
