WEILER E2850 REMIXING TRANSFER VEHICLE
2-10
Machine Controls
2
Machine Controls
(6)
Elevator Raise/Lower Switch
(7) Truck Hitch Switch (Optional)
(8) Engine Stop Button
(9) Horn Button
Press to sound horn.
(10) Hopper Dump Switch
(11) Hopper Vibrator Switch
Push up to raise elevator.
Push down to lower elevator.
Push up to release truck wheels.
Push down to capture truck wheels.
Press in to stop engine quickly.
Pull out to enable engine startup.
Push up to raise dump hopper.
Push down to lower dump hopper.
Push up and hold to turn on vibrator.
10
11
8
9
7
6
STOP
