WEILER E2850 REMIXING TRANSFER VEHICLE
2-22
Machine Controls
2
Machine Controls
(3)
Engine Stop Button
(4) Limp Mode Switch
To propel machine in limp mode, refer to
"Limp
Mode", page 4-5.
Generator 10kW (Optional)
(1) 10kW Generator
(2) Generator Hydraulic Motor
(3) Generator Flow Control Valve
Used to adjust motor speed for generator output
frequency of 60 Hz.
(4) Generator On/Off Button
Turn generator on or off by pressing switch (4).
Engine idle speed ramps up to 1400 rpm from low
idle when generator is on.
Press in to stop engine quickly.
Pull out to enable engine startup.
Push up and hold to move machine forward in
the event of electronic failure.
Push down and hold to move in reverse in the
event of electronic failure.
3
4
1
2
3
RPM
HRS.
° F
DEF
00 %
0.0 0 %
MENU
WASH
DOWN
GAUGE
DATA
GEN.
ON
4
