Weiler E2850 - Machine Terminology

1
WEILER E2850 REMIXING TRANSFER VEHICLE
2-2
Machine Controls
2
Machine Terminology
MACHINE TERMINOLOGY
(1) Battery Box
(2) Discharge Conveyor
(3) Dump Hopper
(4) Dump Hopper Control Station (each side)
(5) Dump Hopper Lights
(6) Elevator
(7) Engine and Pump Compartment
(8) Front Fume Extractor
(9) Headlamps
(10) Operator Station
(11) Rear Fume Extractor
(12) Storage Hopper
(13) Truck Hitch
(14) Truck Signal Lights (Optional)
(15) Work Lights (each side)
Front
Rear
Right
Left
2
3
12
13
7
8
5
6
1
15
9
11
14
4
10
