WEILER E2850 REMIXING TRANSFER VEHICLE
2-12
Machine Controls
2
Machine Controls
Accessory Controls
(1) Dash Lights
Activates lights on main operator station, dump
hopper control boxes, and optional truck signal
lights.
(2) Beacon Switch (Optional)
(3) Headlights
Activates forward facing headlights for low light transport.
(4) Hopper Lights
Activates forward facing lights to illuminate dump hopper.
(5) Work Lights
Activates work lights located near rear of frame and optional conveyor lights pointing into paver
hopper.
Push up to turn dash lights on.
Push down to turn dash lights off.
Push up to turn beacon on.
Push down to turn beacon off.
Push up to turn headlights on.
Push down to turn headlights off.
Push up to turn hopper lights on.
Push down to turn hopper lights off.
Push up to turn work lights on.
Push down to turn work lights off.
1
2
3
5
4
