WEILER E2850 REMIXING TRANSFER VEHICLE
2-24
Machine Controls
2
Machine Controls
Conveyor Spray Down System (Optional)
The Conveyor Spray Down System can be used with either the standard 35-gallon spray down tank or
the 60-gallon spray down tank.
(1) Spray Nozzle Locations
Spray down system includes multiple spray nozzles to
spray chains, sprockets, augers and floor plates of
elevator and conveyors.
(2) Conveyor Spray Down Electronic Display
Screen
1
Typical
WASH DOWN CONTROL
WARNING! CONVEYOR WASH
WILL TURN ON ALL FEEDER
CHAINS WHEN ACTIVATED
CONVEYOR WASH (MANUAL ACTIVE)
ESC
SEC. REMAINING
CYCLE
START
MODE
CONVEYOR WASH MODE
2
