1
WEILER E2850 REMIXING TRANSFER VEHICLE
4-10
Transporting
4
Trailering Machine
7. Use suitable blocking (5) to support conveyor on
trailer.
NOTICE: Do not place conveyor blocking under conveyor
cleanout door tubing (6). Tube damage may occur.
8. Bind conveyor down to trailer. Position tie-down
components (7) directly in line with blocking to keep
from bending conveyor frame.
Unloading
1. Place trailer on a level surface away from overhead obstacles. Chock wheels or set park brake on
tow vehicle.
2. Place and secure appropriate ramps as needed.
3. Install mirrors. Adjust seat and mirrors for best visibility.
4. Remove main operator station vandal cover.
5. Remove tie-downs and chocks.
6. Start engine. Follow
"Machine Starting Procedure", page 3-6.
7. Increase engine speed to full rpm. Place in low gear.
8. Have a spotter on the ground direct the operator. Spotter must stand clear of the machine and be
visible at all times.
9. Slowly drive machine squarely off trailer.
To Next Page
