WEILER E2850 REMIXING TRANSFER VEHICLE
2-8
Machine Controls
2
Machine Controls
(6)
Engine Speed Switch
(7) Distance From Paver Control Engage/Disengage Button
Push once to engage distance from paver control.
Push again to disengage distance from paver control.
Refer to
"Distance From Paver Control System (Optional)", page 3-38 for additional information.
(8) Distance From Paver Control Indicator
Illuminates when distance from paver control system is engaged.
(9) Ignition Switch
NOTICE: Do not hold in start position longer than 30
seconds.
Place in up position for high engine rpm.
Place in center position for medium engine rpm.
Place in down position for low engine rpm (idle).
Center/straight up - engine stop.
1st position clockwise - engine run, electrical
system on.
2nd position clockwise - engine start.
6
7
8
9
