WEILER E2850 REMIXING TRANSFER VEHICLE
3-14
Operating Instructions
3
Preparing Machine
4. Lift Platform Shift Lock Lever (4) and rotate onto
catch before shifting platform.
Shift platform to desired position using Platform
Shift Switch.
5. Place beacon (5) in working position.
6. Raise and secure rear fume extraction stack (6).
7. Lower rear fume extraction stack cradle (7).
8. Tilt steering wheel (8) to raised position by pushing
lever (9) down. Release lever to lock wheel in
position.
4
5
6
7
8
9
