WEILER E2850 REMIXING TRANSFER VEHICLE
B-1
Electronic Display Error Fault Codes
Fault Codes
B
APPENDIX B: FAULT CODES
ELECTRONIC DISPLAY ERROR FAULT CODES
Error descriptions are shown on the View Errors Screen.
ERROR DESCRIPTION ERROR STATE
DISPLAY VOLTAGE HIGH
DISPLAY VOLTAGE GREATER THAN 28 VOLTS FOR 2
SEC.
DISPLAY VOLTAGE LOW DISPLAY VOLTAGE LOWER THAN 6 VOLTS FOR 2 SEC.
CONTROLLER VOLTAGE HIGH
CONTROLLER VOLTAGE GREATER THAN 28 VOLTS FOR
2 SEC.
CONTROL VOLTAGE LOW
CONTROLLER VOLTAGE LOWER THAN 6 VOLTS FOR 2
SEC.
CONTROLLER SENSOR VOLTAGE
HIGH
CONTROLLER VOLTAGE GREATER THAN 6 VOLTS FOR
2 SEC.
CONTROLLER SENSOR VOLTAGE
LOW
CONTROLLER VOLTAGE LOWER THAN 4 VOLTS FOR 2
SEC.
PROPEL FORWARD OUT OF
RANGE
IS GREATER THAN .3A FOR 2 SEC.
PROPEL REVERSE OUT OF RANGE IS GREATER THAN .3A FOR 2 SEC.
ELEVATOR TRANSDUCER
VOLTAGE HIGH
VOLTAGE IS ABOVE 4.9 Vdc.
ELEVATOR TRANSDUCER
VOLTAGE LOW
VOLTAGE IS BELOW .1 Vdc
TWO SPEED COIL OUT OF RANGE
OUTPUT CURRENT IS LESS THAN THE COMMAND
CURREENT BY 15mA, OR MORE, WHEN THE COMMAND
CURRENT IS ON FOR 2 SEC.
PARKING BRAKE OUT OF RANGE
OUTPUT CURRENT IS LESS THAN THE COMMAND
CURRENT BY 15mA, OR MORE, WHEN THE COMMAND
CURRENT IS ON FOR 2 SEC.
PROPEL CALIBRATION HIGH
VOLTAGE IS GREATER THAN PROPEL HI CAL FOR 2
SEC.
PROPEL CALIBRATION LOW VOLTAGE IS LESS THAN PROPEL LO CAL FOR 2 SEC.
PROPEL VOLTAGE HIGH VOLTAGE IS GREATER THAN 4.9 VOLTS FOR 2 SEC.
PROPEL VOLTAGE LOW VOLTAGE IS LESS THAN .1 VOLTS FOR 2 SEC.
PROPEL KNOB CALIBRATION HIGH
VOLTAGE IS GREATER THAN PROPEL HI CAL FOR 2
SEC.
PROPEL KNOB CALIBRATION LOW VOLTAGE IS LESS THAN PROPEL LO CAL FOR 2 SEC.
PROPEL KNOB VOLTAGE HIGH VOLTAGE IS GREATER THAN 4.9 VOLTS FOR 2 SEC.
PROPEL KNOB VOLTAGE LOW VOLTAGE IS LESS THAN .1 VOLTS FOR 2 SEC.
START RELAY CURRENT OUT OF
RANGE
OUTPUT CURRENT IS LESS THAN THE COMMAND
CURRENT BY 15mA, OR MORE, WHEN THE COMMAND IS
ON FOR 2 SEC.
REMIX TRANSDUCER VOLTAGE
HIGH
VOLTAGE IS ABOVE 4.9 Vdc.
