WEILER E2850 REMIXING TRANSFER VEHICLE
2-23
Machine Controls
2
Machine Controls
Hand-Held Spray Down System
The Hand-Held Spray Down System uses the standard 35-gallon (132 L) spray down tank.
(1) Spray Wand
(2) Hand-Held Spray Down Pump Switch
NOTICE: Turn off pump when finished cleaning.
(3) Hand-Held Spray Down Hose Connection
Ports - Quick Disconnect
Connection ports for portable spray down hose.
(4) Hand-Held Spray Down Hose Connection Port -
Stationary
Stationary spray down hose.
Push up to turn spray down pump on.
Push down to turn spray down pump off.
2
1
3
3
3
4
