WEILER E2850 REMIXING TRANSFER VEHICLE
2-36
Machine Controls
2
Machine Controls
View Drive Diagnostics Screen
View Elevator/Conveyor Diagnostics Screen
View Sensor Diagnostics Screen
(1) Press to exit to previous screen.
View CAN Screen
(1) Press to exit to previous screen.
VIEW DRIVE DIAGNOSTICS
PROPEL HANDLE
VOLTAGE 0 (mV)
GROUND DRIVE PUMP
FWD 0 (mA)
REV 0 (mA)
MODE SWITCH LOW
START RELAY 0 (ON/OFF)
TWO SPEED COIL 0 (ON/OFF)
PARK BRAKE 0 (ON/OFF)
STOP BUTTON 0 (ON/OFF)
SIGNAL 0 (#)
PROPEL KNOB
VOLTAGE 0 (mV)
SIGNAL 0 (#)
VIEW ELEVATOR DIAGNOSTICS
ELEVATOR KNOB
VOLTAGE 0 (mV)
STORAGE SWITCH 0 (ON/OFF)
DISCHARGE SWITCH 0 (ON/OFF)
WARM-UP 0 (1=COMPLETE)
ELEVATOR LOAD SHUTDOWN 0 (ON/OFF)
DISCHARGE LOAD SHUTDOWN 0 (ON/OFF)
SIGNAL 0 (#)
STORAGE/DISCHARGE KNOB
VOLTAGE 0 (mV)
SIGNAL 0 (#)
ELEVATOR OUTPUT
0 (mA)
0 (mA)
DISCHARGE OUTPUT
0 (mA)
STORAGE OUTPUT
ELEVATOR SWITCH 0 (ON/OFF)
SENSOR DIAGNOSTICS
ESC
HOPPER LEVEL
SONIC DISTANCE
SONIC SENSOR
RADAR VOLTAGE
RADAR DISTANCE
SET DISTANCE
DISTANCE CONTROL SWITCH
DISTANCE CONTROL ACTIVE
0 PERCENT
0 (INCHES)
0 (mV)
0 (mV)
0.0 FEET
0.0 FEET
0 (ON/OFF)
0 (ON/OFF)
FULL LIGHT
MID LIGHT
LOW LIGHT
0 (ON/OFF)
0 (ON/OFF)
0 (ON/OFF)
VIEW CAN
E2850 DISPLAY REV: VP11
ESC
SCREEN
ENGINE
CONT. 1 CONT. 2
CONT. 3
E2850 CONTROLLER #1 REV: VP0
E2850 CONTROLLER #2 REV: VP0
E2850 CONTROLLER #3 REV: VP0
0.0
VOLTS
0.0
VOLTS
0.0
VOLTS
0.0
VOLTS
0.0
VOLTS
