Weiler E2850 - Page 250

Schematics
C
WEILER E2850 REMIXING TRANSFER VEHICLE
C-58
Schematics
ELECTRICAL SCHEMATIC – S/N 1154–UP
3-BU
2-WH
RH REMOTE FLOAT
.4A
RH REMOTE DASH LAMP
LH REMOTE FLOAT
RH LIFT CYLINDER
2A
2A
2A
AMBER 4968
LH LIFT CYLINDER
AMBER 4968 AMBER 4968
RH REMOTE FLOAT
LH REMOTE FLOAT
6128 6128 6128
DIODE
FLOAT
2
2 2
3 1
1 3 1 3
DIODE
6548
6548
87a
87
FLOAT LATCH
30
87
87a
85
20A, 24V 5180
FLOAT
86
30
20A, 24V 5180
85
86
FLOAT
(8170) (8170)
FLOAT
RH CASTER RAISE "A" COIL
LH CASTER LOWER "B" COIL
LH CASTER RAISE "A" COIL
2A
2A
LH REMOTE DASH LAMP
RH CASTER LOWER "B" COIL
2A
2A
.4A
RH REMOTE LH CASTER
LH REMOTE LH CASTER
LH REMOTE RH CASTER
RH REMOTE RH CASTER
5A 6159
CAMERA
6128 6128 6128 6128
2
3 1
2
1 3
2 2
1 3 1 3
CAMERA (OPT)
6-GY
4-BR
1-RD
CAMERA
5-WH w/YL
TO DASH LAMP SWITCH-TN
62-YL w/BU
60-OR w/BK
61-BU w/WH
118-LT GN 117-LT BU
119-PK
TO RH CONTROL CB-5A
71-OR w/BK
2-RD
111-GY
112-YL
113-BU
114-GN
180-RD
107-TN
GROUND
TO PAGE 7
FROM PAGE 4
FROM PAGE 4
FROM PAGE 4 FROM PAGE 4
PAGE 6
WINDROW HEAD OPTION
