YASKAWA A1000

4.7 Auto-Tuning
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 131
Start-Up Programming & Operation
4
 T2-05: PM Motor Rated Voltage
Sets the motor rated voltage.
 T2-06: PM Motor Rated Current
Enter the motor rated current in amps.
 T2-07: PM Motor Base Frequency
Enter the motor base frequency in Hz.
Note: T2-07 will be displayed when in OLV/PM.
 T2-08: Number of PM Motor Poles
Enter the number of motor poles.
 T2-09: PM Motor Base Speed
Enter the motor rated speed in min
-1
.
Note: T2-09 will be displayed when in AOLV/PM and CLV/PM.
 T2-10: PM Motor Stator Resistance
Enter the motor stator resistance per motor phase.
 T2-11: PM Motor d-Axis Inductance
Enter the d axis inductance per motor phase.
 T2-12: PM Motor q-Axis Inductance
Enter the q axis inductance per motor phase.
No. Name Setting Range Default
<1> The setting range and default value shown here is for a 200 V class drive. These values double when using a 400 V class unit.
T2-05 PM Motor Rated Voltage 0.0 to 255.0 V <1> 200.0 V <1>
No. Name Setting Range Default
T2-06 PM Motor Rated Current
10% to 200% of the drive rated
current.
Depending on o2-04
No. Name Setting Range Default
T2-07 PM Motor Base Frequency 0.0 to 400.0 Hz 87.5 Hz
No. Name Setting Range Default
T2-08 Number of PM Motor Poles 2 to 48 6
No. Name Setting Range Default
T2-09 PM Motor Base Speed
0 to 24000 min
-1
1750 min
-1
No. Name Setting Range Default
T2-10 PM Motor Stator Resistance 0.000 to 65.000 Depending on T2-02
No. Name Setting Range Default
T2-11 PM Motor d-Axis Inductance 0.00 to 600.00 mH Depending on T2-02
No. Name Setting Range Default
T2-12 PM Motor q-Axis Inductance 0.00 to 600.00 mH Depending on T2-02
