5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 259
Parameter Details
5
Setting 1: -10 to 10 Vdc
The input level is -10 to 10 Vdc. Refer to Setting 1: -10 to 10 Vdc on page 257.
Setting 2: 4 to 20 mA
The input level is 4 to 20 mA. Negative input values by negative bias or gain settings will be limited to 0%.
Setting 3: 0 to 20 mA
The input level is 0 to 20 mA. Negative input values by negative bias or gain settings will be limited to 0%.
H3-10: Terminal A2 Function Selection
Determines the function assigned to analog input terminal A2. Refer to Multi-Function Analog Input Terminal Settings
on page 260 for a list of functions and descriptions.
H3-11, H3-12: Terminal A2 Gain and Bias Setting
Parameter H3-11 sets the level of the input value selected that is equal to 10 Vdc input or 20 mA input to terminal A2.
Parameter H3-12 sets the level of the input value selected that is equal
to 0 V, 4 mA or 0 mA input at terminal A2.
Both can be used to adjust the characteristics of
the analog input signal to terminal A2. The setting works in the same
way as parameters H3-03 and H3-04 for analog input A1.
H3-13: Analog Input Filter Time Constant
Parameter H3-13 sets the time constant for a first order filter that will be applied to the analog inputs.
An analog input filter can be used to prevent erratic drive control when a “noisy” analog reference is used. The drive
opera
tion becomes more stable the longer the time programmed, but it becomes less responsive to rapidly changing
analog signals.
H3-14: Analog Input Terminal Enable Selection
When one of the multi-function digital input parameters is set for “Analog input enable” (H1- = C), the value set to
H3-14 determines which of the analog input terminals will be enabled or disabled when the input is closed. All analog
input terminals will be enabled all of the time if H1- is not set to C. The terminals othe
r than the one set as the target
are not influenced by input signals.
Setting 1: A1 only enabled
Setting 2: A2 only enabled
Setting 3: A1 and A2 only enabled
Setting 4: A3 only enabled
Setting 5: A1 and A3 only enabled
Setting 6: A2 and A3 only enabled
Setting 7: All analog i
nput terminals enabled
No. Name Setting Range Default
H3-10 Terminal A2 Function Selection 0 to 32 0
No. Name Setting Range Default
H3-11
Terminal A2 Gain Setting
-999.9 to 999.9% 100.0%
H3-12
Terminal A2 Bias Setting
-999.9 to 999.9% 0.0%
No. Name Setting Range Default
H3-13 Analog Input Filter Time Constant 0.00 to 2.00 s 0.03 s
No. Name Setting Range Default
H3-14 Analog Input Terminal Enable Selection 1 to 7 7
