B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 459
b6: Dwell Function
b5-18
(1DCH)
PID Setpoint Selection
0: Disabled
1: Enabled
Default: 0
Min: 0
Max: 1
175
b5-19
(1DDH)
PID Setpoint Value
Sets the PID target value when b5-18 = 1. Set as a percentage of the maximum PID feedback.
Default: 0.00%
Min: 0.00%
Max: 100.00%
175
b5-20
(1E2H)
PID Setpoint Scaling
Sets the units for setting/display b5-19.
0: 0.01Hz units
1: 0.01% units (100% = max PID Feedback)
2: min
-1
(number of motor poles must entered)
3: User-set (set scaling to b5-38 and b5-39)
Default: 1
Min: 0
Max: 3
176
b5-34
(19FH)
PID Output Lower Limit
Sets the minimum output possible from the PID controller as a percentage of the maximum
output frequency.
Default: 0.00%
Min: -100.0%
Max: 100.0%
176
b5-35
(1A0H)
PID Input Limit
Limits the PID control input (deviation signal) as a percentage of the maximum output
frequency. Acts as a bipolar limit.
Default: 1000.0%
Min: 0.0%
Max: 1000.0%
176
b5-36
(1A1H)
PID Feedback High Detection
Level
Sets the PID feedback high detection level as a percentage of the maximum output frequency.
Default: 100%
Min: 0%
Max: 100%
174
b5-37
(1A2H)
PID Feedback High Detection
Time
Sets the PID feedback high level detection delay time.
Default: 1.0 s
Min: 0.0 s
Max: 25.5 s
174
b5-38
(1FEH)
PID Setpoint User Display
Sets the display value of U5-01 and U5-04 when the maximum frequency is output.
Default:
<5>
Min: 1
Max: 60000
176
b5-39
(1FFH)
PID Setpoint Display Digits
0: No decimal places
1: One decimal places
2: Two decimal places
3: Three decimal places
Default:
<5>
Min: 0
Max: 3
176
b5-40
(17FH)
Frequency Reference Monitor
Content during PID 0: Display the frequency reference (U1-01) after PID compensation has been added.
1: Display the frequency reference (U1-01) before PID compensation has been added.
Default: 0
Min: 0
Max: 1
176
b5-47
(17DH)
Reverse Operation Selection 2 by
PID Output
Reverses operation selection when b5-01 =3 or 4
0: Zero limit when PID output is a negative value
1: Reverse operation when PID output is a negative value (Zero limit if the reverse operation is
prohibited by b1-04)
Default: 1
Min: 0
Max: 1
177
<5> Default setting is dependent on PID setpoint scaling (b5-20).
<6> Default setting value varies by the drive model (o2-04).
<10> Default setting is determined by the control mode (A1-02).
No.(Addr.) Name Description Setting Page
b6-01
(1B6H)
Dwell Reference at Start
Parameters b6-01 and b6-02 set the frequency to hold and the time to maintain that frequency at
start.
Parameters b6-03 and b6-04 set the frequency to hold and the time to maintain that frequency at
stop.
Default: 0.0 Hz
Min: 0.0 Hz
Max: 400.0 Hz
178
b6-02
(1B7H)
Dwell Time at Start
Default: 0.0 s
Min: 0.0 s
Max: 10.0 s
178
b6-03
(1B8H)
Dwell Reference at Stop
Default: 0.0 Hz
Min: 0.0 Hz
Max: 400.0 Hz
178
b6-04
(1B9H)
Dwell Time at Stop
Default: 0.0 s
Min: 0.0 s
Max: 10.0 s
178
No.(Addr.) Name Description Setting Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
