B.7 Parameters that Change with the Motor Code Selection (for PM Motors)
534 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
Table B.17 400 V, 1450 min
-1
Type YASKAWA SSR1 Series IPM Motor
No.
<6> Default setting value varies by the drive model (o2-04).
Name Unit Default Settings
E5-01
Motor Code Selection (for PM Motors)  1332 1333 1335 1336 1338 133A 133B 133D 133E 133F
Voltage Class V 400 400 400 400 400 400 400 400 400 400
Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18
Rated Speed
min
-1
1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power (for PM Motors) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.50
E5-03 Motor Rated Current (for PM Motors) A 0.94 1.56 2.81 4.27 6.98 10.21 13.85 19.5 27.4 32.9
E5-04 Number of Motor Poles (for PM Motors) – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Stator Resistance (r1) (for PM
Mo
tors)
 12.760 7.421 4.825 2.656 1.353 0.999 0.713 0.393 0.295 0.223
E5-06
Motor d-Axis Inductance (Ld) (for PM
Mo
tors)
mH 128.60 85.11 58.87 46.42 31.73 26.20 27.06 15.51 12.65 9.87
E5-07
Motor q-Axis Inductance (Lq) (for PM
Mo
tors)
mH 166.96 113.19 80.59 60.32 40.45 30.94 33.45 19.63 15.87 12.40
E5-09
Motor Induction Voltage Constant 1 (Ke)
(f
or PM Motors)
mVs/rad 528.6 544.2 568.5
572.8 562.9 587.6 670.1 612.7 624.6 610.4
E5-24
Motor Induction Voltage Constant 2 (Ke)
(f
or PM Motors)
mV/(min
-1
)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency
min
-1
(Hz)
1450
(72.5
)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
E1-05 Maximum Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency
min
-1
(Hz)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
E1-09 Minimum Output Frequency
min
-1
(Hz)
72
(3.6
)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
C5-17 Motor Inertia
kgm
2
0.0017 0.0023 0.0043 0.0083 0.0136 0.017 0.027 0.046 0.055 0.064
L3-24
<6>
Motor Acceleration Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.080
n5-02 Motor Acceleration Time s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.080
n8-49
d-Axis Current for High Efficiency
C
ontrol (for PM Motors) (OLV/PM)
% -6.6 -9.2 -13.5 -12.1 -13.7 -10.1 -12.2 -15.5 -15.1 -16.0
No.
<6> Default setting value varies by the drive model (o2-04).
Name Unit Default Settings
E5-01
Motor Code Selection (for PM Motors)  1340 1342 1343 1344 1345 1346 1347 1348 1349
Voltage Class V 400 400 400 400 400 400 400 400 400
Rated Power kW22303745557590110132
Rated Speed
min
-1
1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power (for PM Motors) kW 22.00 30.00 37.00 45.00 55.00 75.00 90.00 110.00 132.00
E5-03 Motor Rated Current (for PM Motors) A 37.6 52.5 63.2 76.4 96.1 124.0 153.1 186.5 226.0
E5-04Number of Motor Poles (for PM Motors)–666666666
E5-05
Motor Stator Resistance (r1) (for PM
Motors)
 0.164 0.137 0.093 0.059 0.048 0.028 0.024 0.015 0.011
E5-06
Motor d-Axis Inductance (Ld) (for PM
Motors)
mH 7.90 7.01 5.93 4.17 3.11 2.32 2.20 1.45 1.23
E5-07
Motor q-Axis Inductance (Lq) (for PM
Motors)
mH 10.38 8.68 6.79 5.22 4.55 2.97 3.23 1.88 1.67
E5-09
Motor Induction Voltage Constant 1 (Ke)
(for PM Motors)
mVs/rad 655.4 708.4 739.2 703.0 747.1 639.3 708.0 640.7 677.0
E5-24
Motor Induction Voltage Constant 2 (Ke)
(for PM Motors)
mV/(min
-1
)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency
min
-1
(Hz)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
E1-05 Maximum Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency
min
-1
(Hz)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
1450
(72.5)
E1-09 Minimum Output Frequency
min
-1
(Hz)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
72
(3.6)
C5-17 Motor Inertia
kgm
2
0.116 0.140 0.259 0.312 0.42 0.56 0.83 0.96 1.61
L3-24
<6>
Motor Acceleration Time for Inertia
Calculations
s 0.122 0.108 0.161 0.160 0.175 0.171 0.213 0.201 0.281
n5-02 Motor Acceleration Time s 0.122 0.108 0.161 0.160 0.175 0.171 0.213 0.201 0.281
n8-49
d-Axis Current for High Efficiency
Control (for PM Motors) (OLV/PM)
% -15.7 -11.5 -6.8 -11.5 -14.8 -15.8 -19.6 -14.9 -15.1
