6-38
IM DLM6054-01EN
Frame Skip (Frame Skip)
This feature skips frames in cases such as when the color burst is inverted for every frame. You can
select how many frames to skip.
1 The DL6000/DLM6000 triggers on the specified field of every frame.
2 The DL6000/DLM6000 skips one frame and triggers on the specified field of the subsequent
frame. This operation is repeated every two frames.
4 The DL6000/DLM6000 skips three frames and triggers on the specified field of the
subsequent frame. This operation is repeated every four frames.
8 The DL6000/DLM6000 skips seven frames and triggers on the specified field of the
subsequent frame. This operation is repeated every eight frames.
User-Defined (Userdef TV)
You can specify custom values for the definition, horizontal sync frequency, sync guard frequency, and
other settings.
Trigger Source (Source), Polarity (Polarity), Trigger Level (Level), Line Number (Line),
Field Number (Field), and Frame Skip (Frame skip)
These settings are the same as the settings for specific broadcasting systems.
HF Rejection (HF Rejection)
Select whether or not to remove high-frequency components (300 kHz or higher) from the trigger
signal.
300kHz:
High-frequency components greater than or equal to 300 kHz are removed.
OFF: High-frequency components are not removed.
When the broadcasting system is not set to User Define, the HF rejection setting is configured as
follows:
NTSC, P
AL, and SDTV:
Fixed at 300 kHz
HDTV
: Fixed at OFF
Note
Hold-off, trigger coupling, and HF rejection settings are ignored.
Horizontal Sync Frequency (HSync)
Set the horizontal sync frequency. Pressing RESET sets the frequency to 31.5 kHz.
Definition (Definition)
You can set the definition to one of the following options.
SD: Standard (bi-level sync signal)
HD: High definition (tri-level sync signal)
6.10 Triggering on a TV Trigger
To Next Page
