Event Reference Time
For Event Cycle
You can set the reference time to a value from 1.5 ns to 10.00 s in 0.5 ns steps.
Note
The DL6000/DLM6000 may not trigger properly if the spacing between signals or the signal pulse width is
less than 2 ns. Under standard operating conditions, the time width accuracy is ±(0.2% of the set value + 1
ns) immediately after calibration. The “set value” in the above expression is the T2 value when T1 < Pulse <
T2.
For Event Delay and Event Sequence
• When event 1 and event 2 are both based on analog signals or both based on logic signal bits,
you can set each of the reference times to a value from 1.5 ns to 10.00 s in 0.5 ns steps.
• When event 1 and event 2 are based on dif
ferent types of signals (one is based on a logic signal
bit and the other is based on an analog signal), you can set each of the reference times to a
value from 20.0 ns to 10.00 s in 0.5 ns steps.
Note
• When event 1 and event 2 are both based on analog signals or both based on logic signal bits, the
DL6000/DLM6000 may not trigger properly if the spacing between signals or the signal pulse width is less
than 2 ns. Under standard operating conditions, the time width accuracy is ±(0.2% of the set value + 1 ns)
immediately after calibration. The “set value” in the above expression is the T2 value when T1 < Pulse <
T2.
• When event 1 and event 2 are based on different types of signals (one is based on a logic signal bit and
the other is based on an analog signal), the time width accuracy is ±(0.2% of the set value + 10 ns). The “set
value” in the above expression is the T2 value when T1 < Pulse < T2.
Event Type
You can use any trigger as an event except for Edge OR, TV, and UART triggers. For more details,
see the various sections that explain triggering.
Event Source
Sent an event source that matches the specified event type. For more details, see the various sections
that explain triggering.
6.11 Triggering on Period, Delay, and Sequence Events
