Computed and Reference Waveforms
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
Explanation
You can define up to four original expressions.
Expressions (Expression)
Define expressions by combining computation source waveforms and operators.
You can enter up to 128 characters.
Computation Source Waveforms
You can use the following waveform data.
Menu Item Description
C1 to C4 CH1 to CH4
M1 to M3 You can use M1 when Setup Trace is set to M2. You can use M1 and M2 when Setup Trace is
set to M3 or M4. You can use M1 to M3 when Setup Trace is set to M4.
T Amount of time elapsed from the screen’s left edge
Operators
You can combine the following operators to define expressions.
Menu Item Example Description
Basic functions
+,-,*,/ C1+C2-C3 Basic arithmetic of input values
ABS ABS(C1) Absolute value of an input value
SQRT SQRT(C2) Square root of an input value
LOG LOG(C1) Logarithm of an input value
LN LN(C1) Natural logarithm of an input value
EXP EXP(C1) Exponent of an input value
P2 P2(C1) Square of an input value
- -(C1) Opposite of an input value
Trigonometric functions
SIN SIN(C1) Sine of an input value
ASIN ASIN(C1) Arc sine of an input value
COS COS(C1) Cosine of an input value
ACOS ACOS(C1) Arc cosine of an input value
TAN TAN(C1) Tangent of an input value
ATAN ATAN(C1) Arc tangent of an input value
PH PH(C1,C2) Phase difference between two input values
Differentiation and integration
DIFF DIFF(C1) Derivative of an input waveform
INTEG INTEG(C1) Integral of an input waveform
Filter functions
FILT1 FILT1(C1) Application of a digital filter to the input waveform
FILT2 FILT2(C1) Application of a digital filter to the input waveform
HLBT HLBT(C1) Hilbert function of the input waveform
MEAN MEAN(C1,10) Moving average of an input waveform
DELAY DELAY(C1,0.001) Phase shifting of an input waveform
BIN BIN(CH1,1,-1) Binary conversion of an input waveform
Pulse width computation
PWHH PWHH(C1,1,-1) Pulse width computation of an input waveform from one rising edge
to the next rising edge
PWHL PWHL(C1,1,-1) Pulse width computation of an input waveform from a rising edge to
the next falling edge
PWLH PWLH(C1,1,-1) Pulse width computation of an input waveform from a falling edge to
the next rising edge
PWLL PWLL(C1,1,-1) Pulse width computation of an input waveform from one falling edge
to the next falling edge
PWXX PWXX(C1,1,-1) Pulse width computation of the input waveform from one rising or
falling edge to the next rising or falling edge
FV FV(C1,1,-1) Reciprocal of the computed pulse width PWHH
DUTYH DUTYH(C1,1,-1) Duty ratio of the high side of each period of an input waveform
DUTYL DUTYL(C1,1,-1) Duty ratio of the low side of each period an input waveform
