YOKOGAWA DL6000 Series User Manual

9-19
IM DLM6054-01EN
Computed and Reference Waveforms
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
• Frequency Band (Band)
You can set the frequency band to one of the settings below.
• LowPass
• BandPass
• HighPass
• Cutoff Frequency (Cutoff1/Cutoff2)
Set the cutoff frequency separately for Filter1 and Filter2.
Settable range: 2.0% to 30.0% of the sampling frequency
Resolution: 0.2% of the sampling frequency
Computed Data Averaging (Average)
Set whether or not to perform linear averaging on the results of user-defined computation. This
setting applies M1 through M4.
• A
verage Count (Average Count)
Settable range: 2 to 1024 in 2
n
steps
Note
• If you change the computation conditions while computed data averaging is on, the computed data up to
that point is cleared.
• You cannot average computed data if the trigger mode is set to N Single.
• You cannot average computed data during waveform acquisition.
• You cannot average computed data that has been recomputed after waveform acquisition.
Computation on History Waveforms (Math on History)
This feature performs computation on all history waveforms.
If waveform acquisition is stopped and you press the Math on History soft key, the DL6000/DLM6000
performs userdefined computation on all of the source channel’s history waveforms.
Note
• You cannot execute [Math on History] during waveform acquisition.
• While [Math on History] is in progress, the “computing” icon and progress bar appear at the top of the
screen. All operations except for that of the Abort soft key are invalid.
• If you set the trigger mode to N Single and start waveform acquisition, after acquisition stops, the DL6000/
DLM6000 only performs user-defined computation on the last acquired waveform. To perform user-
defined computation on all history waveforms, press the Math on History soft key.
• If you change a setting that would affect the results of user-defined computation, the DL6000/DLM6000
only recomputes the values of the selected history waveform.
• If an error occurs in the average display or statistical processing of a history waveform, press the Math on
History soft key.
9.10 Performing User-Defined Computations (Optional)
