14-9
IM DLM6054-01EN
Ethernet Interface (Optional)
14
Explanation
One of the actions that you can select in the action-on-trigger and GO/NO-GO determination features
is the transmission of e-mails containing trigger times and other information to a specific e-mail
address.
Mail Server (Mail Server)
Specify the IP address of the network e-mail server. In a network with a WINS or DNS server, you can
specify the NetBIOS name or the host name and domain name instead of the IP address.
E-mail Address (Address)
To Address: Using up to 100 characters, you can specify multiple addresses on the network to
send e-mails to. Separate the addresses with commas.
From Address: Y
ou can specify the address of the sender using up to 40 characters. If you do not
specify a From Address, the To Address is used.
Comment (Comment)
The first line of the e-mail that will be sent. Use this setting as necessary. You can enter up to 100
characters.
Attaching Screen Captures (Attached Image)
You can attach a capture of the screen that is displayed at the time the e-mail is sent.
• File format: PNG
• File name: DL_image[date and time].png (Example: DL Image0802171158.png is the file name
that would be created on 2008/2/17 at 11:58.)
• Resolution:
XGA (1024 × 768 dots)
• Approximate file size
• Normal screen:
Approx. 50 KB
• Maximum: Approx. 1.6 MB
*
* For screen captures that contain a large amount of color information.
User Authentication (POP3 before SMTP)
Before you send an e-mail, POP3 user authentication is performed.
• Mode
ON:
Authentication is performed before e-mails are sent.
OFF: Authentication is not performed before e-mails are sent.
• Encryption type
U/P:
The authentication data is sent in plaintext.
APOP: The authentication data is encrypted before it is sent.
• Server name
Using up to 30 characters, enter the POP3 server host name o
r IP address.
• User name
Using up to 30 characters, enter the user name that the DL600
0/DLM6000 will need to access the
POP3 server.
• Password
Using up to 30 characters, enter the password that the DL600
0/DLM6000 will need to access the
POP3 server.
Timeout (Time Out)
Specify the timeout period for sending and receiving. You can set the timeout to a value between 1 and
60 s in 1 s steps. The default value is 15 s.
14.4 Configuring E-Mail Transmission (SMTP client function)
