18-20
IM DLM6054-01EN
Item Specifications
Immunity Compliant standard
EN61326-1 Table2(for industrial environment) T
able2(for industrial environment)Table2(for industrial environment)
Applicable to the DL6054, DL6104, DL6154, DLM6054, DLM6104, 701939, 701912,, DL6104, DL6154, DLM6054, DLM6104, 701939, 701912,DLM6054, DLM6104, 701939, 701912,
01913, 701914, 701923, 701974 with 701975, 701980
1
, 701981
1
, 701935
2
EN61326-2-1
Influence in the immunity testing environment (criteria A)
Noise
increase:
Within ±200 mV (when using the 701939 or 701974 with 701975)
Within ±2 V (when using the 701913 or 701923)
Logic signal polarity inversion does not occur (when using the 701980 or
701981)
1
Test
conditions:
2.5 GS/s, envelope mode, 20 MHz BWL (10:1 probe attenuation setting),
1
Cable
conditions:
Same as the emission cable conditions.
Test items: 1. Static discharge: EN61000-4-2
Air discharge: ±8 kV. Contact discharge: ±4 kV. Criteria B.
2. Radiated immunity: EN61000-4-3
80 M to 1 GHz, 10 V/m, 1.4 to 2 GHz, 3 V/m, 2.0 to 2.7 GHz, 3 V/m,
criteria A
3. Conducted immunity: EN61000-4-6
3 V, criteria A
4. EFT/Burst: EN61000-4-4
Power line: ±2 kV. Signal line: ±1 kV, criteria B
5. Power frequency magnetic fields: EN61000-4-8
330 A/m, 50 Hz, criteria A
6. Surge immunity: EN61000-4-5
±1 kV between lines, ±2 kV common, criteria B
7. Voltage dip and interruptions: EN61000-4-11
1 cycle, both polarities, 100%, criteria B
Other tests, criteria C
Definitions of criteria A, B, and C
Criteria A: During testing, "influence in the immunity testing environment"
described above is met.
Criteria B:: The instrument continues to function and is controllable
throughout testing. The instrument does not change operation
modes, and data changes do not persist.
Criteria C: During testing, temporary degradation of performance or loss
of functionality occurred, the correction of which required
user operation or system reset.
1 Logic only available on the DLM6000.
2 The 701935 is
YOKOGAWA’s Deskew Correction Signal Source.
18.11 General Specifications
