To Next Page

To Previous Page

Making Preparations for Measurements

3-5

IM DLM6054-01EN

Index

App

Rubber Feet

DL6000

Rubber stoppers can be attached to the four feet on the bottom and two locations on the back of the

DLM6000. Six rubber stoppers are included with the DLM6000.

DLM6000

Rubber stoppers can be attached to the four feet on the bottom of the DLM6000. Four rubber stoppers

are included with the DLM6000.

DL6000 DLM6000

Four stoppers Four stoppers

Two stoppers located

on the left and right

3.2 Installing the Instrument
