Center Position after the Execution of Auto Setup
The center position after you execute auto setup will be 0.00 div.
Affected Channels
Auto setup is performed on all channels.
Waveforms Displayed before the Execution of Auto Setup
When you perform auto setup, the data in the acquisition memory is overwritten, and the waveforms
that were displayed before you executed auto setup are cleared.
Undoing Auto Setup
After you execute auto setup, you can press the Undo soft key to return to the previous settings.
The Undo soft key that appears when you press AUTO SETUP will disappear when you change setup
menus or press ESC, but you can still undo the auto setup by pressing SETUP MENU and then the
Undo soft key.
Signals That Auto Setup Can Be Applied To
Frequency Approx. 50 Hz or higher
Absolute input voltage Max. value of approx. 20 mV or greater (when the probe attenuation is set to 1:1)
Type Simple, repeating signals
Note
The auto setup feature may not work properly for some signals, such as those that include a DC component
or high-frequency components.
