4-14
IM DLM6054-01EN
Settings after the Execution of Auto Setup
CH1 to CH4 settings
Position 0div
Coupling Settings other than DC50
Ω
are set to DC1M
Ω
.
Settings of DC50
Ω
do not change.
BW FULL
Offset 0V
Invert OFF
Acquisition settings
Mode Normal
High Resolution OFF
Sampling and length settings
Sampling Mode Interpolation
Interleave OFF
Length 125kpoints
Trigger settings
Mode Auto
HoldOff 20ns
Delay OFF
Position 50%
Type Edge
Polarity Rise
Coupling DC
Hysteresis Small
HF Rej OFF
Window OFF
Accumulation settings
Mode OFF
Screen settings
Mapping Auto
Dot Connect Sine
Intensity 8
Brightness 8
Zoom settings
Zoom OFF
Main ON
Cursor settings
Display OFF
Waveform parameter settings
Display OFF
Mask settings
Display OFF
Analysis settings
Display OFF
Settings that depend on the input signal
CH On/Off On if the DL6000/DLM6000 detects a voltage of ±7 mV or higher
and Off otherwise
V/div The range that has the highest sensitivity and that does not
exceed ±3.5 divisions
Trigger Level Center
Trigger Source The channel with the lowest frequency among the signals whose
amplitude (Max – Min) is at least 1 division
TIME/DIV The fastest time axis setting that allows at least two periods of
the fastest signal among the signals whose amplitude is at least
1 division to be observed. The time axis setting must be at least 5
ms/division.
Display Format One to four areas depending on the number of active channels
4.5 Performing Auto Setup
