5-16 IM 701450-01E
Explanation
The computation shown below is executed using the specified coefficient A and offset B.
The cursor measurement values and automated measurement values of waveform
parameters are displayed using the scaled values. A unit can be attached to the scaled
values.
Y = AX + B (where X is the measured value and Y is the linear scaling result)
Setting Scaling Coefficient A and Offset Value B
Selectable range of A and B –9.9999E+30 to +9.9999E+30
Default settings A 1.0000E+00
B 0.0000E+00
Setting the Unit
You can set the unit using up to four alphanumeric characters.
Displaying the Scale Value
The upper and lower limits of the vertical axis of each channel can be displayed using
scaled values (scale values). For the procedure of displaying scale values, see section
8.8.
5.9 Using the Linear Scaling Function
To Next Page
